Case 570NXT - Page 258

8-SPECIFICATIONS
Twowheeldrivemachineswith19.5Lx24reartires
Longlipbucket4in1bucket
A.Overalloperatingheight,fullyraised4167mm(164.1in)4350mm(171.3in)
B.Heighttobuckethingepin,fullyraised3413mm(134.4in)
C.Overallheight,travelposition2739mm(107.8in)
D.Overalllengthwithbucketontheground
withthreepointhitch
5154mm(202.9in)5088mm(200.3in)
with1361kg(3000lb)rearcounterweight4950mm(194.9in)4884mm(192.3in)
E.Dumpangleatfullheight46°45°
2720mm(107.1in) F.Dumpheight,45°dump2642mm(104in)
2942mm(115.8in)
withclamopen
647mm(25.5in) G.Dumpreach,45°dump660mm(26.0in)
302mm(11.9in)
withclamopen
H.Dumpheight
SameasF .
I.Dumpheight
SameasG.
J.Rollbackatground
40°
K.HeighttobuckethingepinatSAEcarry323mm(12.7in)372mm(14.6in)
L.BucketrollbackatSAEcarry45°45°
M.Bucketrollbackatfullheight
Adjustable
172mm(6.8in) N.Diggingdepthbelowgrade,withbucketat191mm(7.5in)
103mm(4.1in)
withclamopen
P .Wheelbase
2134mm(84in)
Overallwidth(reartires)2077mm(81.8in)
Bucketcuttingedgewidth
2085mm(82.1in)2083mm(82.0in)
Groundclearancebetweentires(driveshaftguard)313mm(12.3in)
Groundclearance,frontaxledifferential276mm(10.9in)
