8-SPECIFICATIONS
Fourwheeldrivemachineswith19.5Lx24reartires
Longlipbucket4in1bucket
A.Overalloperatingheight,fullyraised4170mm(164.2in)4353mm(171.4in)
B.Heighttobuckethingepin,fullyraised3405mm(134.1in)
C.Overallheight,travelposition2741mm(107.9in)
D.Overalllengthwithbucketontheground
withthreepointhitch
5154mm(202.9in)5088mm(200.3in)
with1361kg(3000lb)rearcounterweight4950mm(194.9in)4884mm(192.3in)
E.Dumpangleatfullheight46°45°
2712mm(106.8in) F.Dumpheight,45°dump2934mm(115.5in)
2634mm(103.7in)
withclamopen
644mm(25.4in) G.Dumpreach,45°dump657mm(25.9in)
299mm(11.8in)
withclamopen
H.Dumpheight
SameasF .
I.Dumpheight
SameasG.
J.Rollbackatground
40°
K.HeighttobuckethingepinatSAEcarry326mm(12.8in)371mm(14.6in)
L.BucketrollbackatSAEcarry45°45°
M.Bucketrollbackatfullheight
Adjustable
180mm(7.1in) N.Diggingdepthbelowgrade,withbucketat199mm(7.8in)
111mm(4.4in)
withclamopen
P .Wheelbase
2146mm(84.5in)
Overallwidth(reartires)2077mm(81.8in)
Bucketcuttingedgewidth
2085mm(82.1in)2083mm(82.0in)
Groundclearancebetweentires(driveshaftguard)313mm(12.3in)
Groundclearance,frontaxledifferential276mm(10.9in)
