3-CONTROLS/INSTRUMENTS
Suspensionseat
Swivel:
Liftthelevertoswivelthepositionoftheseat
15°or30°totheright.
NOTE:Theseatonlyswivelstotheright.
RCPH10TLB433AAF4
Forward/rearward:
Liftthelevertomovetheseatforwardor
rearward.Releasetheleverandensurethe
seatislockedinposition.
RCPH10TLB433AAF5
Backresttilt:
Locatedontheleft-handsideoftheseat.Liftthelever
totilttheseatbackrest.Releasethelevertolockthe
backrestinposition.
RAPH12UTL0093AA6
3-3
