3-CONTROLS/INSTRUMENTS
Horn:
Pushthehornemblemtosoundthehorn.
Releasetodeactivatethehorn.
RAPH12UTL0019AA2
Transmissiongearshiftlever:
Thetransmissionshiftlever(2)islocatedtotherightof
thesteeringcolumn.Presstheclutchcutoutbutton(1)
beforeyouselect1of4gears.Releasetheclutchcutout
buttontoengagetheclutchaftershifting.
Clutchcutout:
Theclutchcutoutbutton(1)letstheengine
increasespeedandsupplytheloaderwith
morehydraulicoilforgreaterloaderpower
andfastercontrolfunction.Whenyoupush
theclutchcutoutbutton,thetransmissionis
disengagedfromthedrivewheels.Release
theclutchcutoutbuttontoengagethe
transmissionpower.Themachinecanmove
freelywhentheclutchcutoutbuttonispushed.
Ifrequired,usetheservicebraketostopthe
machine.
NOTE:Aclutchcutoutbuttonisalsoontheloadercontrol
handle.
