Parkingbrake
TheparkingbrakeisaSpringAppliedHydraulicReleased(SAHR)brake.Theparkingbrakeshouldbeappliedif
theengineisstopped.Theparkingbrakeisalwaysengagedonstartup.Atstartup,cycletheswitchfromthepark
emblemtotheOemblem.Cycletheswitch,regardlessofthepositiontheswitchwasinatstartup.
Pressthetopemblemoftherockerswitchto
settheparkingbrake.
Pressthebottomemblemtoreleasethe
parkingbrake.
NOTICE:Transmissionisdeclutchedwhentheparking
brakeisengaged.
RAPH12UTL0089AA8
Loaderquickcoupler,ifequipped
Presstheemblemoftherockerswitchto
disconnectthecouplerfromtheattachment.
Presstheemblemtoconnect(couple)tothe
attachment.
RAPH12UTL0022AA9
Rotatingbeacon,ifequipped
Presstheemblemendoftherockerswitchto
activatethebeaconlight.Presstheopposite
endtoturnoffthebeaconlight.
