3-CONTROLS/INSTRUMENTS
Stopengine:
NOTICE:Alwaysstopthemachineandshutdownthe
enginewheneverthislampilluminates.
Dangerlamp.Illuminateswithacontinuous
audiblealarmwhenacriticalconditionis
detectedbythevehiclecontrollerorengine
controller.
Examplesofcriticalconditions:
•
enginecoolanttemperatureistoohigh.
•
engineoilpressureistoolowortoohigh.
•
DieselParticulateFilter(DPF)ashlevel
reachedacriticallevel(enginede-ratewill
occur).Contactanauthorizedfacilityto
replaceorcleantheDPF.
•
unauthorizedsoftwareupgrades(engine
de-ratewilloccur)
RCPH10TLB138AAF4
Alternator:
Warninglamp.Illuminateswhen,withthe
enginerunning,thealternatorisnotcharging
thebattery.
RCPH10TLB138AAF5
Parkingbrake:
Indicatorlamp.Illuminateswhentheparking
brakeisset.
RCPH10TLB138AAF6
3-20
