3-CONTROLS/INSTRUMENTS
Lowfuellevel:
Warninglamp.Illuminatesandaonesecond
audiblealarmsoundswhenthefuellevelis
low.
RCPH10TLB138AAF11
Gaugesandmeters
Enginecoolanttemperature:
Indicatesthecoolanttemperatureofthe
engine.Thetemperatureofthecoolantis
normalwhenthegaugeneedleisinthegreen
areaofthegauge.Whenthegaugeneedle
goestotheendoftheredarea(lasttickmark),
acontinuousaudiblealarmwillsound.Stop
theengineandcheckthelevelofthecoolant
inthecoolantreservoir,checkfordebrison
theradiator/oilcooler,and/orcheckfora
thermostatthatdoesnotoperatecorrectly.
RCPH10TLB138AAF12
Oiltemperature,torqueconverter:
Indicatestheoiltemperatureofthetorque
converter.Thetemperatureoftheoilisnormal
whenthegaugeneedleisinthegreenarea
ofthegauge.Whenthegaugeneedlegoes
totheendoftheredarea(lasttickmark),a
continuousaudiblealarmwillsound.
Whenthegaugeneedlegoesintothered
area,movethedirectioncontrollevertothe
neutralpositionandruntheengineatfull
throttle.Ifthisproceduredoesnotreducethe
temperatureoftheoil,checktheoilleveland
checkforobstructionintheradiatorandoil
cooler.
RCPH10TLB138AAF13
Tachometer:
ShowstheenginespeedinRevolutionsPer
Minute(RPM).Eachtickmarkonthegaugeis
equalto100RPM.Itisrecommendedthatthe
engineberuninthegreenareaofthegauge.
RCPH10TLB138AAF14
3-22
