Chapter 8 – Appendix
Section 8.2 – Summary of Operator Steps
8-5
Begin a
Treatment
Step Action
1. Use the arrow buttons to select the ‘Run Treatment’
option.
2. Press the ‘Enter’ button. The ‘Select number of containers
to treat’ screen will appear.
Load
Processing
Sets
Refer to Section 4.3 for details.
Step Action
1. Use the arrow buttons to select the number of containers
to illuminate.
2. Press the ‘Enter’ button.
3. Open the front door of the illuminator.
4. Pull out the drawer.
5. Open the cover of the tray by sliding the black latch to
the right. (The cover will open to the right.)
6. Place the illumination container, marked with number 1,
into the front illumination chamber 1, in the left-hand side
of the tray.
7. Secure the container flap onto the plastic hook in the
tray.
8. Put the tubing from the illumination container in the slot of
the divider. Make sure that the sealed tubing containing
the platelets is within left-hand side of the chamber.
9. Place other containers into the right-hand side of the front
chamber 1 so that the final storage container label is
facing up.
10. Secure the set to the drawer by putting alignment holes
over the pegs.
To Next Page
