124 Functional Description CG Drives & Automation, 01-5326-01r5
User-defined Unit [323]
This menu is only displayed if User is selected in menu
[322]. The function enables the user to define a unit with six
symbols. Use the Prev and Next key to move the cursor to
required position. Then use the + and - keys to scroll down
the character list. Confirm the character by moving the
cursor to the next position by pressing the Next key.
Example:
Create a user unit named kPa.
1. When in the menu [323] press to show the cur-
sor.
2. Press to move the cursor to the right most posi-
tion.
3. Press until the character a is displayed.
4. Press .
5. Then press the until P is displayed and press
.
6. Repeat until you have entered kPa, confirm with
.
Communication information
Character
No. for serial
comm.
Character
No. for serial
comm.
Space 0 m 58
0–9 1–10 n 59
A11 ñ60
B12 o61
C13 ó 62
D14 ô63
E15p64
F16q65
G17 r 66
H18 s 67
I19t68
J20u69
K21 ü70
L22v71
M23 w72
N24 x 73
O25 y 74
P26 z 75
Q27 å 76
R28 ä77
S29 ö78
T30! 79
U31 ¨ 80
Ü32 #81
V33$82
W34 %83
X35&84
Y36 · 85
Z37( 86
Å38 ) 87
Ä39 * 88
Ö40 + 89
a41, 90
á42- 91
b43. 92
c44/ 93
d45: 94
e46; 95
é47<96
ê48=97
ë49>98
f50?99
g51@100
h52^101
i53_102
í54
°
103
j552104
k563105
l57
323 User Unit
Default: No characters shown
Modbus Instance no/DeviceNet no: 43304 - 43309
Profibus slot/index
169/208 -
169/213
EtherCAT and CANopen index (hex) 4ce8 - 4ced
Profinet IO index 19688 - 19693
Fieldbus format UInt
Modbus format UInt
Character
No. for serial
comm.
Character
No. for serial
comm.
