CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 179
Max Alarm 20
The max alarm level has been
reached.
Max PreAlarm 21
The max pre alarm level has been
reached.
Min Alarm 22
The min alarm level has been
reached.
Min PreAlarm 23
The min pre alarm Level has been
reached.
LY 24 Logic output Y.
!LY 25 Logic output Y inverted.
LZ 26 Logic output Z.
!LZ 27 Logic output Z inverted.
CA 1 28 Analogue comparator 1 output.
!A1 29 Analogue comp 1 inverted output.
CA 2 30 Analogue comparator 2 output.
!A2 31 Analogue comp 2 inverted output.
CD 1 32 Digital comparator 1 output.
!D1 33 Digital comp 1 inverted output.
CD 2 34 Digital comparator 2 output.
!D2 35 Digital comp 2 inverted output.
Operation 36
Run command is active or AC drive
running. The signal can be used to
control the mains contactor if the AC
drive is equipped with Standby
supply option.
T1Q 37 Timer1 output
!T1Q 38 Timer1 inverted output
T2Q 39 Timer2 output
!T2Q 40 Timer2 inverted output
Sleeping 41 Sleeping function activated
Crane Deviat 42 Tripped on deviation
PumpSlave1 43 Activate pump slave 1
PumpSlave2 44 Activate pump slave 2
PumpSlave3 45 Activate pump slave 3
PumpSlave4 46 Activate pump slave 4
PumpSlave5 47 Activate pump slave 5
PumpSlave6 48 Activate pump slave 6
PumpMaster
1
49 Activate pump master 1
PumpMaster
2
50 Activate pump master 2
PumpMaster
3
51 Activate pump master 3
PumpMaster
4
52 Activate pump master 4
PumpMaster
5
53 Activate pump master 5
PumpMaster
6
54 Activate pump master 6
All Pumps 55 All pumps are running
Only Master 56 Only the master is running
Loc/Rem 57
Local/Rem mode indication
Local = 1, Remote = 0
Standby 58 Standby supply option is active
PTC Trip 59 Trip when function is active
PT100 Trip 60 Trip when function is active
Overvolt 61 Overvoltage due to high main voltage
Overvolt G 62 Overvoltage due to generation mode
Overvolt D 63 Overvoltage due to deceleration
Acc 64 Acceleration along the acc. ramp
Dec 65 Deceleration along the dec. ramp
I
2
t66I
2
t limit protection active
V-Limit 67 Overvoltage limit function active
C-Limit 68 Overcurrent limit function active
Overtemp 69 Over temperature warning
Low voltage 70 Low voltage warning
DigIn 1 71 Digital input 1
DigIn 2 72 Digital input 2
DigIn 3 73 Digital input 3
DigIn 4 74 Digital input 4
DigIn 5 75 Digital input 5
DigIn 6 76 Digital input 6
DigIn 7 77 Digital input 7
DigIn 8 78 Digital input 8
ManRst Trip 79
Active trip that needs to be manually
reset
Com Error 80 Serial communication lost
External Fan 81
The AC drive requires external
cooling. Internal fans are active.
LC Pump 82 Activate liquid cooling pump
LC HE Fan 83
Activate liquid cooling heat
exchanger fan
LC Level 84 Liquid cooling low level signal active
Run Right 85
Positive speed (>0.5%), i.e. forward/
clockwise direction.
Run Left 86
Negative speed (<0.5%), i.e. reverse
counter clockwise direction.
Com Active 87 Fieldbus communication active.
Brk Fault 88 Tripped on brake fault (not released)
BrkNotEngag
e
89
Warning and continued operation
(keep torque) due to Brake not
engaged during stop.
Option 90
Failure occurred in built-in option
board.
