CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 197
Timer 1 Mode [642]
Selection of mode of operation for Timer.
Communication information
Timer 1 Delay [643]
This menu is only visible when timer mode is set to delay.
This menu can only be edited as in alternative 2, see section
Chapter 10.6 page 84.
Timer 1 delay sets the time that will be used by the first
timer after it is activated. Timer 1 can be activated by a high
signal on a DigIn that is set to Timer 1 or via a virtual
destination [560].
Communication information
Timer 1 T1 [644]
When timer mode is set to Alternate and Timer 1 is enabled,
this timer will automatically keep on switching according to
the independently programmable on and off times. The
Timer 1 in Alternate mode can be enabled by a digital input
or via a virtual connection. See Fig. 140. Timer 1 T1 sets the
on time in the alternate mode.
Communication information
Timer 1 T2 [645]
Timer 1 T2 sets the off time in the alternate mode.
Communication information
642 Timer1 Mode
Default: Off
Off 0
Delay 1
Alternate 2
Modbus Instance no/DeviceNet no: 43432
Profibus slot/index 170/81
EtherCAT and CANopen index (hex) 4d68
Profinet IO index 19816
Fieldbus format UInt
Modbus format UInt
643 Timer1Delay
Default: 0:00:00 (hr:min:sec)
Range: 0:00:00–9:59:59
Modbus Instance no/DeviceNet no:
43433 hours
43434 minutes
43435 seconds
Profibus slot/index
170/82, 170/83,
170/84
EtherCAT and CANopen index (hex) 4d69, 4d6a, 4d6b
Profinet IO index 19817, 19818, 19819
Fieldbus format UInt, 1=1 h/m/s
Modbus format UInt, 1=1 h/m/s
644 Timer 1 T1
Default: 0:00:00 (hr:min:sec)
Range: 0:00:00–9:59:59
Modbus Instance no/DeviceNet no:
43436 hours
43437 minutes
43438 seconds
Profibus slot/index
170/85, 170/86,
170/87
EtherCAT and CANopen index (hex) 4d6c, 4d6d, 4d6e
Profinet IO index 19820, 19821, 19822
Fieldbus format UInt, 1=1 h/m/s
Modbus format UInt, 1=1 h/m/s
645 Timer1 T2
Default: 0:00:00, hr:min:sec
Range: 0:00:00–9:59:59
Modbus Instance no/DeviceNet no:
43439 hours
43440 minutes
43441 seconds
Profibus slot/index
170/88, 170/89,
170/90
EtherCAT and CANopen index (hex) 4d6f, 4d70, 4d71
Profinet IO index 19823, 19824, 19825
Fieldbus format UInt, 1=1 h/m/s
Modbus format UInt, 1=1 h/m/s
NOTE: “Timer 1 T1 [644]” and “Timer 1 T2 [645]” are
only visible when Timer Mode is set to Alternate.
