CG Drives & Automation 01-5326-01r5 Technical Data 239
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block ( power module).
Table 55 Typical motor power at mains voltage 460 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame
size
(Number
of
PEBB´s)**
IP
class
Power
@460V
[HP]
Rated
current
[A]
Power
@460V
[HP]
Rated
current
[A]
48-003-54 3.8 1 2.5 1 2.0
B
IP 54
wall
mounted
48-004-54 6.0 2 4.0 1.5 3.2
48-006-54 9.0 3 6.0 2 4.8
48-008-54 11.3 3 7.5 3 6.0
48-010-54 14.3 5 9.5 3 7.6
48-013-54 19.5 7.5 13.0 5 10.4
48-018-54 27.0 10 18.0 7.5 14.4
48-026-54 39 15 26 10 21
C
48-031-54 46 20 31 15 25
48-037-54 55 25 37 20 29.6
48-046-54 69 30 46 25 37
48-061-54 92 40 61 30 49
D
48-074-54 111 50 74 40 59
48-090-54 108 60 90 50 72
E
48-109-54 131 75 109 60 87
48-146-54 175 100 146 75 117
48-175-54 210 125 175 100 140
48-210-54 252 150 210 125 168
F
48-228-54 300 200 228 150 182
48-250-54 300 200 250 150 200
48-295-54 354 250 295 200 236
48-365-54 438 300 365 250 292 FA
48-300-IP 360 250 300 200 240
G(2)
IP 20
module
or IP54
cabinet
48-375-IP 450 300 375 250 300
48-430-IP 516 350 430 250 344
H(2)
48-500-IP 600 400 500 350 400
48-600-IP 720 500 600 400 480
I(3)48-650-IP 780 550 650 400 520
48-750-IP 900 600 750 500 600
48-860-IP 1032 700 860 550 688
J(4)
48-1K0-IP 1200 800 1000 650 800
48-1K15-IP 1380 900 1150 750 920
KA(5)
48-1K25-IP 1500 1000 1250 800 1000
48-1K35-IP 1620 1100 1350 900 1080
K(6)
48-1K5-IP 1800 1250 1500 1000 1200
48-1K75-IP 2100 1500 1750 1200 1400 L(7)
48-2K0-IP 2400 1700 2000 1300 1600 M(8)
48-2K25-IP 2700 1900 2250 1500 1800 N(9)
48-2K5-IP 3000 2100 2500 1700 2000 O(10)
Larger sizes available on request
