CG Emotron VFX Series User Manual

CG Drives & Automation 01-5326-01r5 Technical Data 241
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 57 Typical motor power at mains voltage 575 and 690 V. AC drive main voltage range 500 - 690 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
(Number of
PEBB´s)**
IP
class
Power
@575V
[HP]
Power
@690V
[kW]
Rated
current
[A]
Power
@575V
[HP]
Power
@690V
[kW]
Rated
current
[A]
69-002-54 3.2 1.5 1.5 2 1 0.75 1.6
C69
IP 54
wall
mounted
69-003-54 4.8 2 2.2 3 1.5 1.5 2.4
69-004-54 6.4 3 3 4 2 2.2 3.2
69-006-54 9.6 4 4 6 3 3 4.8
69-008-54 12.8 5 5.5 8 4 4 6.4
69-010-54 16 7.5 7.5 10 5 5.5 8
69-013-54 20.8 10 11 13 7.5 7.5 10.4
69-018-54 29 15 15 18 10 11 14.4
69-021-54 34 20 18.5 21 15 15 16.8
69-025-54 40 25 22 25 20 18.5 20
69-033-54 53 30 30 33 25 22 26
D69
69-042-54 67 40 37 42 30 30 34
69-050-54 80 50 45 50 40 37 40
69-058-54 93 60 55 58 40 45 46
69-082-54 98 75 75 82 60 55 66
F69
69-090-54 108 75 90 90 60 75 72
69-109-54 131 100 110 109 75 90 87
69-146-54 175 125 132 146 100 110 117
69-175-54 210 150 160 175 125 132 140
69-200-54 240 200 200 200 150 160 160
69-250-IP 300 250 250 250 200 200 200
H69 (2)
IP 20
module
or IP54
cabinet
69-300-IP 360 300 315 300 250 250 240
69-375-IP 450 350 355 375 300 315 300
69-400-IP 480 400 400 400 300 315 320
69-430-IP 516 400 450 430 350 315 344
I69 (3)69-500-IP 600 500 500 500 400 355 400
69-595-IP 720 600 600 600 500 450 480
69-650-IP 780 650 630 650 550 500 520
J69 (4)
69-720-IP 864 750 710 720 600 560 576
69-800-IP 960 850 800 800 650 630 640
69-905-IP 1080 950 900 900 750 710 720
KA69 (5)
69-995-IP 1200 1000 1000 1000 850 800 800
69-1K2-IP 1440 1200 1200 1200 1000 900 960 K69 (6)
69-1K4-IP 1680 1500 1400 1400 1200 1120 1120 L69 (7)
69-1K6-IP 1920 1700 1600 1600 1300 1250 1280 M69 (8)
69-1K8-IP 2160 1900 1800 1800 1500 1400 1440 N69 (9)
69-2K0-IP 2400 2100 2000 2000 1700 1600 1600 O69 (10)
69-2K2-IP 2640 2300 2200 2200 1800 1700 1760 P69 (11)
69-2K4-IP 2880 2500 2400 2400 2000 1900 1920 Q69 (12)
69-2K6-IP 3120 2700 2600 2600 2200 2000 2080 R69 (13)
69-2K8-IP 3360 3000 2800 2800 2400 2200 2240 S69 (14)
69-3K0-IP 3600 3200 3000 3000 2500 2400 2400 T69 (15)
