CG Drives & Automation 01-5326-01r5 Technical Data 245
* Enclosure height/Total height
Table 60 Mechanical specifications, VFX69 for IP20 module and IP54
Models Frame size
IP20 module
Dim. H x W x D
mm (in)
IP54
Dim. H x W x D
mm (in)
Weight IP20
kg (lb)
Weight IP54
kg (lb)
002 to 025 C69 -
440/512* x 178 x 314
(17.3/20.2 x 7.0 x 12.4)
– 17 (37.5)
033 to 058 D69 -
545/590* x 220 x 282
(21.5/23.2 x 8.7 x 11.1)
– 32 (70.5)
082 to 200 F69 –
1090 x 345 x 312
(42.9 x 13.6 x 12.3)
– 77 (169.8)
250 to 375 H69 (2xF69)
1176 x 500 x 450
(46.3 x 19.7 x 17.7)
2250 x 600 x 600
(88.6 x 23.6 x 23.6)
176 (388) 399 (879.6)
430 to 595 I69 (3xF69)
1176 x 730 x 450
(46.3 x 28.7 x 17.7)
2250 x 900 x 600
(88.6 x 35.4 x 23.6)
257 (566.6) 563 (1241)
650 to 800 J69 (2xH69)
1176 x 1100 x 450
(46.3 x 43.3 x 17.7)
2250 x 1200 x 600
(88.6 x 47.2 x 23.6)
352 (776) 773 (1704)
905 to 995
KA69
(H69+I69)
1176 x 1365 x 450
(46.3 x 53.7 x 17.7)
2250 x 1500 x 600
(88.6 x 59.1 x 23.6)
433 (954.6) 937 (2066)
750 to 1K2 K69 (2xI69)
1176 x 1630 x 450
(46.3 x 64.2 x 17.7)
2250 x 1800 x 600
(88.6 x 70.9 x 23.6)
514 (1133) 1100 (2425)
1K4
L69
(2xH69+I69)
1176 x 2000 x 450
(46.3 x 78.7 x 17.7)
2250 x 2100 x 600
(88.6 x 82.7 x 23.6)
609 (1343) 1311 (2890)
1K6
M69
(H69+2xI69)
1176 x 2230 x 450
(46.3 x 87.8 x 17.7)
2250 x 2400 x 600
(88.6 x 94.5 x 23.6)
690 (1521) 1481 (3265)
1K8 N69 (3xI69)
1176 x 2530 x 450
(46.3 x 99.6 x 17.7)
2250 x 2700 x 600
(88.6 x 106.3 x 23.6)
771 (1700) 1651 (3640)
2K0
O69
(2xH69+2xI69)
1176 x 2830 x 450
(46.3 x 111.4 x 17.7)
2250 x 3000 x 600
(88.6 x 118.1 x 23.6)
866 (1909) 1849 (4076)
2K2
P69
(H69+3xI69)
1176 x 3130 x 450
(46.3 x 123.2 x 17.7)
2250 x 3300 x 600
(88.6 x 129.9 x 23.6)
947 (2088) 2050 (4519)
2K4 Q69 (4xI69)
1176 x 3430 x 450
(46.3 x 135 x 17.7)
2250 x 3600 x 600
(88.6 x 141.7 x 23.6)
1028 (2266) 2214 (4881)
2K6
R69
(2xH69+3xI69)
1176 x 3730 x 450
(46.3 x 146.9 x 17.7)
2250 x 3900 x 600
(88.6 x 153.5 x 23.6)
1123 (2476) 2423 (5342)
2K8
S69
(H69+4xI69)
1176 x 4030 x 450
(46.3 x 158.7 x 17.7)
2250 x 4200 x 600
(88.6 x 165.4 x 23.6)
1204 (2654) 2613 (5761)
3K0 T69 (5xI69)
1176 x 4330 x 450
(46.3 x 170.5 x 17.7)
2250 x 4500 x 600
(88.6 x 177.2 x 23.6)
1285 (2833) 2777 (6122)
