7 - MAINTENANCE
Manutenzione utente (ME2000S)
ME2000S - User Manual
113 - 133
B
B
1
2
7.1.3 Gripper lubrication
After having thoroughly cleaned the guide (1) of the Y-axis clamp carriage with a cloth to remove the dust, lightly
lubricate it (with just a few drops of oil).
Then move (B) the carriage (2) by hand to distribute the oil evenly and make sure that the carriage runs smoothly.
Contact technical support if you notice any friction while doing this
Only use liquid synthetic oil with a viscosity of about 60-68 mm2/sec at 40°
7.1.4 Loading hopper lubrication
Put oil the holes of the loading hopper
