6 - USE AND OPERATION
Schermate display (ME)
ME2000S - User Manual
84 - 133
X emboss adjustment: -0.5 mm
Y emboss adjustment: 0.5 mm
X unload adjustment: -0.8 mm
Y unload adjustment: -0.8 mm
X stand-by adjustment: 0.0 mm
Y stand-by adjustment: 0.0 mm
Reversed char: no
SET UP
HOME
BACK
X unload adjustment: Sets the tag release/unload position on the X-axis.
Y unload adjustment: Sets the tag release/unload position on the Y-axis.
X stand-by adjustment: Sets the starting position of the gripper on the X-axis.
Y stand-by adjustment: Sets the starting position of the gripper on the Y-axis.
Reversed char: Use a character set rotated by 180°.
