3 - SAFETY
Rischi residui (ME)
ME2000S - User Manual
34 - 133
3
2
3
1
1
WARNING / AVERTISSEMENT
MOVING PARTS
Keep body parts out of the motion path
PARTIES MOBILES
Se tenir à lécart de la zone de mouvement
3.4 Residual risks
Some accessible parts should be considered hazardous for the operator, as moving parts can be reached if the
upper door sensor is faulty. To avoid being hurt and to prevent injury, the operator must be made aware of the moving
parts to be careful of, so that they can keep their hands and body parts away from the danger zone:
Ref. Zone Description of hazard
1
Carriage and gripper
CRUSHING HAZARD
Risk of crushing in the vicinity of the left and right end stops.
2
Embossing drum
ENTRAPMENT HAZARD
Risk of entrapment due to the rotation of the drum.
3
Embossing drum
CRUSHING HAZARD
Risk of crushing at the upper and lower embossing punches.
WARNING AVERTISSEMENT
Hazardous Moving Parts. Keep body parts out
of the motion path.
Parties mobiles dangereuses. Se tenir à lécart
de la zone de mouvement des parties mobiles.
