2 - MACHINE DESCRIPTION
Dati tecnici ME2000S
ME2000S - User Manual
26 - 133
1
3
2
2.5 Principle of operation
In order to produce a tag, the machine carries out a sequential cycle, the steps of which can be briey summarized
as follows:
Loading Embossing
abcd efg
123
Unloading
Loading
The tag (1) is ejected from the loading hopper (2) and transferred to the pick-up zone where it is collected by the
gripper unit (3).
