Cisco 2100 Series Configuration Guide

8-42
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 8 Controlling Mesh Access Points
Viewing Mesh Statistics and Reports
Mesh Node
Security Stats
Transmitted Packets The number of packets transmitted during security
negotiations by the selected mesh access point.
Received Packets The number of packets received during security
negotiations by the selected mesh access point.
Association Request
Failures
The number of association request failures that occur
between the selected mesh access point and its parent.
Association Request
Timeouts
The number of association request timeouts that occur
between the selected mesh access point and its parent.
Association Requests
Successful
The number of successful association requests that occur
between the selected mesh access point and its parent.
Authentication
Request Failures
The number of failed authentication requests that occur
between the selected mesh access point and its parent.
Authentication
Request Timeouts
The number of authentication request timeouts that occur
between the selected mesh access point and its parent.
Authentication
Requests Successful
The number of successful authentication requests
between the selected mesh access point and its parent.
Reassociation Request
Failures
The number of failed reassociation requests between the
selected mesh access point and its parent.
Reassociation Request
Timeouts
The number of reassociation request timeouts between
the selected mesh access point and its parent.
Reassociation
Requests Successful
The number of successful reassociation requests between
the selected mesh access point and its parent.
Reauthentication
Request Failures
The number of failed reauthentication requests between
the selected mesh access point and its parent.
Reauthentication
Request Timeouts
The number of reauthentication request timeouts that
occur between the selected mesh access point and its
parent.
Reauthentication
Requests Successful
The number of successful reauthentication requests that
occur between the selected mesh access point and its
parent.
Unknown Association
Requests
The number of unknown association requests received by
the parent mesh access point from its child. The unknown
association requests often occur when a child is an
unknown neighbor mesh access point.
Invalid Association
Requests
The number of invalid association requests received by
the parent mesh access point from the selected child mesh
access point. This state may occur when the selected
child is a valid neighbor but is not in a state that allows
association.
Table 8-7 Mesh Access Point Statistics (continued)
Statistics Parameter Description

Cisco 2100 Series Specifications

General

Power over Ethernet (PoE)	No
Form Factor	Desktop
Encryption	AES, TKIP
Maximum Access Points	6
Security	WPA, WPA2, 802.1X
Dimensions	1.75 x 8.0 x 8.5 in. (4.4 x 20.3 x 21.6 cm)
