8-41
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 8 Controlling Mesh Access Points
Viewing Mesh Statistics and Reports
Table 8-7 Mesh Access Point Statistics
Statistics Parameter Description
Mesh Node Stats Malformed Neighbor
Packets
The number of malformed packets received from the
neighbor. Examples of malformed packets include
malicious floods of traffic such as malformed or short
DNS packets and malformed DNS replies.
Poor Neighbor SNR
Reporting
The number of times the signal-to-noise ratio falls below
12 dB on the backhaul link.
Excluded Packets The number of packets received from excluded neighbor
mesh access points.
Insufficient Memory
Reporting
The number of insufficient memory conditions.
Rx Neighbor Requests The number of broadcast and unicast requests received
from the neighbor mesh access points.
Rx Neighbor
Responses
The number of responses received from the neighbor
mesh access points.
Tx Neighbor Requests The number of unicast and broadcast requests sent to the
neighbor mesh access points.
Tx Neighbor
Responses
The number of responses sent to the neighbor mesh
access points.
Parent Changes Count The number of times a mesh access point (child) moves
to another parent.
Neighbor Timeouts
Count
The number of neighbor timeouts.
Queue Stats Gold Queue The average and peak number of packets waiting in the
gold (video) queue during the defined statistics time
interval.
Silver Queue
The average and peak number of packets waiting in the
silver (best effort) queue during the defined statistics
time interval.
Platinum Queue The average and peak number of packets waiting in the
platinum (voice) queue during the defined statistics time
interval.
Bronze Queue The average and peak number of packets waiting in the
bronze (background) queue during the defined statistics
time interval.
Management Queue The average and peak number of packets waiting in the
management queue during the defined statistics time
interval.
