5-248 Cisco 7000 Hardware Installation and Maintenance
Replacing Internal Components
• Check the arbiter board and ensure that it is fully seated in the backplane port by
pushing the connector edge firmly into the backplane port.
• Remove and reseat the SP (or SSP) in the slot. Use the ejector tabs to eject the card out
of the slot, then simultaneously press both tabs inward (press the top ejector down and
the bottom ejector up) to push the card into the backplane connectors.
• Replace the front chassis panels. Turn ON the power supplies and repeat Steps 1 and 2.
Step 4 If after several attempts the arbiter does not appear to be functioning properly, or if you
experience trouble with the installation (for instance, if the holes in the board do not align
with the backplane holes), contact a customer service representative for assistance.
This completes the arbiter replacement.
Note All spares are shipped with detailed, up-to-date instructions (called configuration notes) for
installing and, if applicable, configuring the spare.
If you must return the chassis to the factory, be sure to remove all power supplies and to repack the
chassis in the original shipping container. If the shipping container and packing material are no
longer available, contact a customer service representative for instructions.
