Cisco 7000 Hardware Installation And Maintenance

A-258 Cisco 7000 Hardware Installation and Maintenance
Serial Adapter Cable Pinouts
Table A-12 EIA-530 DTE Adapter Cable Signals
FSIP End, HD
60-Position
Plug DTE Cable
1
1. EIA-530 is not available in DTE mode.
Network End,
DB-25 Plug
Signal Pin Pin Signal
Shield ground 46 1 Shield ground
TxD/RxD+ 11 —> 2 TxD+
TxD/RxD– 12 —> 14 TxD–
RxD/TxD+ 28 <— 3 RxD+
RxD/TxD– 27 <— 16 RxD–
RTS/CTS+ 9 —> 4 RTS+
RTS/CTS– 10 —> 19 RTS–
CTS/RTS+ 1 <— 5 CTS+
CTS/RTS– 2 <— 13 CTS–
DSR/DTR+ 3 <— 6 DSR+
DSR/DTR– 4 <— 22 DSR–
DCD/DCD+ 5 <— 8 DCD+
DCD/DCD– 6 <— 10 DCD–
TxC/RxC+ 24 <— 15 TxC+
TxC/RxC– 23 <— 12 TxC–
RxC/TxCE+ 26 <— 17 RxC+
RxC/TxCE– 25 <— 9 RxC–
LL/DCD 44 —> 18 LL
Circuit ground 45 7 Circuit ground
DTR/DSR+ 7 —> 20 DTR+
DTR/DSR– 8 —> 23 DTR–
TxCE/TxC+ 13 —> 24 TxCE+
TxCE/TxC– 14 —> 11 TxCE–
Mode_1
Ground
Mode_2
49
48
47
Shorting group
Ground
Mode_DCE
51
52
Shorting group
