Chapter 44 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
This example shows how to enable the guest VLAN feature and to specify VLAN 5 as a guest VLAN:
Cisco IOS Release 12.2(50)SG and later
Switch# configure terminal
Switch(config)# dot1x guest-vlan supplicant
Switch(config)# interface gigabitethernet5/9
Switch(config-if)# switchport mode access
Switch(config-if)# dot1x pae authenticator
Switch(config-if)# authentication event no-response action authorize vlan 5
Switch(config-if)# authentication port-control auto
Switch(config-if)# end
Switch#
Cisco IOS Release 12.2(46)SG or earlier
Switch# configure terminal
Switch(config)# dot1x guest-vlan supplicant
Switch(config)# interface gigabitethernet5/9
Switch(config-if)# switchport mode access
Switch(config-if)# dot1x pae authenticator
Switch(config-if)# dot1x guest-vlan 5
Switch(config-if)# dot1x port-control auto
Switch(config-if)# end
Switch#
Configuring 802.1X with MAC Authentication Bypass
To enable MAC Authentication Bypass (MAB), perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# interface
interface-id
Specifies the port to be configured, and enters interface configuration
mode.
Step 3
Switch(config-if)# switchport mode
access
or
Switch(config-if)# switchport mode
private-vlan host
Specifies a nontrunking, nontagged single VLAN Layer 2 interface.
Specifies that the ports with a valid PVLAN trunk association become active
host PVLAN trunk ports.
Step 4
Switch(config-if)# dot1x pae
authenticator
Enables 802.1X authentication on the port with default parameters.
Refer to the “Default 802.1X Configuration” section on page 44-27.
Step 5
Cisco IOS Release 12.2(50)SG and later
Switch(config-if)# authentication
port-control auto
Cisco IOS Release 12.2(46)SG or earlier
releases
Switch(config-if)# dot1x
port-control auto
Enables 802.1X authentication on the interface.
Step 6
Cisco IOS Release 12.2(50)SG and later
Switch(config-if)# mab [eap]
Cisco IOS Release 12.2(46)SG or earlier
releases
Switch(config-if)# dot1x
mac-auth-bypass [eap]
Enables MAB on a switch.
The eap option specifies that a complete EAP conversation should be
used, as opposed to standard RADIUS Access-Request, Access-Accept
conversation. By default, the eap option is not enabled for MAB.
