Chapter 22 Configuring Resilient Ethernet Protocol
Monitoring REP
Configuring SNMP Traps for REP
To configure the switch to send REP-specific traps to notify the SNMP server of link operational status
changes and port role changes, perform this task:
To remove the trap, enter the no snmp mib rep trap-rate global configuration command.
This example configures the switch to send REP traps at a rate of 10 per second:
Switch(config)# snmp mib rep trap-rate 10
Monitoring REP
To monitor REP, enter the following privileged EXEC commands (Table 22-1).
Step 3
Switch(config-if)# rep preempt segment
segment-id
Manually triggers VLAN load balancing on the segment.
You must confirm the command before it is executed.
Step 4
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 5
Switch# show rep topology
Displays REP topology information.
Command Purpose
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# snmp mib rep trap-rate value
Enables the switch to send REP traps, and set the number of
traps sent per second. The range is from 0 to 1000. The default
is 0 (no limit imposed; a trap is sent at every occurrence).
Step 3
Switch(config)# end
Returns to privileged EXEC mode.
Step 4
Switch# show running-config
Verifies the REP trap configuration.
Step 5
Switch# copy running-config startup config
(Optional) Saves your entries in the switch startup
configuration file.
Table 22-1 REP Monitoring Commands
Command Purpose
Switch# show interface [interface-id] rep
[detail]
Displays REP configuration and status for a
specified interface or for all interfaces.
Switch# show rep topology [segment
segment_id
] [archive] [detail]
Displays REP topology information for a segment
or for all segments, including the primary and
secondary edge ports in the segment.
