Cisco Catalyst 4500 Series Configuration Guide

19-5
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 19 Configuring Cisco IOS Auto Smartport Macros
Configuring Auto Smartport Macros
Table 19-2 shows the Auto Smartport built-in macros that are embedded in the switch software.
Note By default, the built-in event triggers are mapped to the built-in macros.
Auto Smartport Configuration Guidelines
Auto Smartport guidelines include the following:
• To avoid system conflicts when Auto Smartport macros are applied, remove all port configuration
except for 802.1X authentication.
• If the macro conflicts with the original configuration, some macro commands might not be applied,
or some antimacro commands might not be applied. (The antimacro is the portion of the applied
macro that removes it at link down.)
Note Failure of one command in the macro halts the application of the entire macro.
For example, if 802.1X authentication is enabled, you cannot remove switchport-mode access
configuration. You must remove the 802.1X authentication before removing the configuration.
• A port should not be a member of an EtherChannel when applying Auto Smartport macros.
If Auto Smartport is not yet enabled globally, disable Auto Smartport on all the EtherChannel ports
before enabling it globally. If Auto Smartport is already enabled, shut down the port and disable it
before adding the port to an EtherChannel.
Table 19-2 Auto Smartport Built-in Macros
Macro Name Description
CISCO_PHONE_AUTO_
SMARTPORT
Use this macro for Cisco IP phone device. It enables QoS, port security,
Address Resolution Protocol (ARP) inspection (dynamic ARP inspection),
IP source guard, DHCP snooping, storm control and spanning tree
protection on the port.
CISCO_SWITCH_AUTO_
SMARTPORT
Use this macro to apply the switch macro for Cisco switches. It enables
trunking on the port.
CISCO_ROUTER_AUTO_
SMARTPORT
Use this macro to apply the router macro for Cisco routers. It enables QoS,
trunking, and spanning-tree protection on the port.
CISCO_AP_AUTO_
SMARTPORT
Use this macro to apply the wireless access point (AP) macro for Cisco
APs. It enables support for an autonomous wireless access point and QoS
on the port.
CISCO_LWAP_AUTO_
SMARTPORT
Use this macro to apply the lightweight wireless access point macro for
Cisco lightweight wireless APs. It enables QoS, port security, dynamic
ARP inspection, IP source guard, DHCP snooping, storm control, and
spanning tree protection on the port.
CISCO_IP_CAMERA_AUTO_SMARTPORT Use this macro for a Cisco IP surveillance camera device. It enables QoS,
port security, and access VLAN on the port.
CISCO_DMP_AUTOSMARTPORT Use this macro for a Cisco digital media player device. It enables QoS, port
security, and access VLAN on the port.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
