Cisco Catalyst 4500 Series Configuration Guide

44-73
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 44 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
Figure 44-16 User Set Up
Note The procedure is the same for voice devices except that the AAA server must be configured to send a
Cisco Attribute-Value (AV) pair attribute with a value of device-traffic-class=voice.
Enabling Fallback Authentication
On a port in multiauthentication mode, either or both of MAB and web-based authentication can be
configured as fallback authentication methods for non-802.1X hosts (those that do not respond to
EAPOL). You can configure the order and priority of the authentication methods.
For detailed configuration information for MAB, see the “Configuring 802.1X with MAC
Authentication Bypass” section on page 44-58.
For detailed configuration information for web-based authentication, see Chapter 46, “Configuring
Web-Based Authentication.”
Note When web-based authentication and other authentication methods are configured on an MDA or
multiauthentication port, downloadable ACL policies must be configured for all devices attached to that
port.
To enable fallback authentication, perform this task:
Command Purpose
Step 1
Switch(config)# ip admission name rule-name proxy
http
Configures an authentication rule for web-based
authentication.
Step 2
Switch(config)# fallback profile profile-name
Creates a fallback profile for web-based authentication.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
