Page #857 background imageLoading...
Page #857 background image
39-11
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 39 Configuring VRF-lite
Configuring Multicast VRFs
Configuring Multicast VRFs
To configure multicast within a VRF table, perform this task:
For more information about configuring a multicast within a Multi-VRF CE, see the
Cisco IOS IP Multicast Configuration Guide, Release 12.4.
Use the no ip vrf vrf-name global configuration command to delete a VRF and to remove all interfaces
from it. Use the no ip vrf forwarding interface configuration command to remove an interface from the
VRF.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ip routing
Enables IP routing.
Step 3
Switch(config)# ip vrf vrf-name
Names the VRF and enters VRF configuration mode.
Step 4
Switch(config-vrf)# ip
multicast-routing vrf vrf-name
(Optional) Enables global multicast routing for VRF table.
Step 5
Switch(config-vrf)# rd
route-distinguisher
Creates a VRF table by specifying a route distinguisher.
Enter either an AS number and an arbitrary number
(xxx:y) or an IP address and arbitrary number
(A.B.C.D:y).
Step 6
Switch(config-vrf)# route-target
{export | import | both}
route-target-ext-community
Creates a list of import, export, or import and export route
target communities for the specified VRF. Enter either an
AS system number and an arbitrary number (xxx:y) or an
IP address and an arbitrary number (A.B.C.D:y).
The route-target-ext-community value should be the same
as the route-distinguisher value entered in Step 4.
Step 7
Switch(config-vrf)# import map
route-map
(Optional) Associates a route map with the VRF.
Step 8
Switch(config-vrf)# interface
interface-id
Enters interface configuration mode and specifies the
Layer 3 interface to be associated with the VRF. The
interface can be a routed port or a SVI.
Step 9
Switch(config-if)# ip vrf forwarding
vrf-name
Associates the VRF with the Layer 3 interface.
Step 10
Switch(config-if)# ip address
ip-address mask
Configures IP address for the Layer 3 interface.
Step 11
Switch(config-if)# ip pim
[sparse-dense mode | dense-mode |
sparse-mode]
Enables PIM on the VRF-associated Layer 3 interface.
Step 12
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 13
Switch# show ip vrf [brief | detail |
interfaces
] [vrf-name]
Verifies the configuration. Display information about the
configured VRFs.
Step 14
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
