Chapter 11 Configuring Cisco NSF with SSO Supervisor Engine Redundancy
Configuring NSF with SSO Supervisor Engine Redundancy
Configuring SSO
You must configure SSO in order to use NSF with any supported protocol.
To configure SSO, perform this task:
Note The sso keyword is supported in Cisco IOS Release 12.2(20)EWA and later releases.
This example shows how to configure the system for SSO and display the redundancy state:
Switch> enable
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# redundancy
Switch(config-red)# mode sso
Switch(config-red)# end
Switch# show redundancy states
my state = 13 -ACTIVE
peer state = 8 -STANDBY HOT
Mode = Duplex
Unit = Primary
Unit ID = 5
Redundancy Mode (Operational) = sso
Redundancy Mode (Configured) = sso
Split Mode = Disabled
Manual Swact = Enabled
Communications = Up
client count = 29
client_notification_TMR = 30000 milliseconds
keep_alive TMR = 9000 milliseconds
keep_alive count = 1
keep_alive threshold = 18
RF debug mask = 0x0
Switch#
Configuring CEF NSF
The CEF NSF feature operates by default while the networking device is running in SSO mode. No
configuration is necessary.
Command Purpose
Step 1
Switch(config)# redundancy
Enters redundancy configuration mode.
Step 2
Switch(config-red)# mode sso
Configures SSO. When this command is entered, the
redundant supervisor engine is reloaded and begins to
work in SSO mode.
Step 3
Switch(config-red)# end
Returns to EXEC mode.
Step 4
Switch# show running-config
Verifies that SSO is enabled.
Step 5
Switch# show redundancy states
Displays the operating redundancy mode.
