Chapter 10 Configuring Supervisor Engine Redundancy Using RPR and SSO on Supervisor Engine 7-E and Supervisor
About Supervisor Engine Redundancy
and related publications at this location:
http://www.cisco.com/en/US/products/ps6350/index.html
About Supervisor Engine Redundancy
These sections describe supervisor engine redundancy:
• Overview, page 10-2
• RPR Operation, page 10-3
• SSO Operation, page 10-3
Overview
With supervisor engine redundancy enabled, if the active supervisor engine fails or if a manual
switchover is performed, the standby supervisor engine becomes the “new” active supervisor engine.
The standby supervisor engine has been automatically initialized with the startup configuration of the
active supervisor engine, shortening the switchover time (30 seconds or longer in RPR mode, depending
on the configuration; subsecond in SSO mode).
In addition to the reduced switchover time, supervisor engine redundancy supports the following:
• Online insertion and removal (OIR) of the supervisor engine.
Supervisor engine redundancy allows OIR of the redundant supervisor engine for maintenance.
When the redundant supervisor engine is inserted, the active supervisor engine detects its presence,
and the redundant supervisor engine boots into a partially-initialized state in RPR mode and a
fully-initialized state in SSO mode.
• Software upgrade. (See the “Performing a Software Upgrade” section on page 10-12.)
To minimize down time during software changes on the supervisor engine, load the new image on
the standby supervisor engine, and conduct a switchover.
When power is first applied to a switch, the supervisor engine that boots first becomes the active
supervisor engine and remains active until a switchover occurs.
A switchover will occur when one or more of the following events take place:
• The active supervisor engine fails (due to either hardware or software function) or is removed.
• A user forces a switchover.
• A user reloads the active supervisor engine.
Table 10-1 provides information about chassis and supervisor engine support for redundancy.
Table 10-1 Chassis and Supervisor Support
Supported Switches Supported Supervisor Engines
WS-C4507R-E, WS-C4510R-E,
WS-C4507R+E, WS-C4510R+E
Supervisor Engine 7-E (WS-X45-SUP7-E) and
Supervisor Engine 7L-E (WS-X45-SUP7L-E)

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
