Cisco Catalyst 4500 Series Configuration Guide

50-28
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 50 Configuring DHCP Snooping, IP Source Guard, and IPSG for Static Hosts
Configuring IP Source Guard for Static Hosts
200.1.1.4 0001.0600.0000 8 GigabitEthernet3/1 INACTIVE
200.1.1.5 0001.0600.0000 8 GigabitEthernet3/1 INACTIVE
200.1.1.6 0001.0600.0000 8 GigabitEthernet3/1 INACTIVE
200.1.1.7 0001.0600.0000 8 GigabitEthernet3/1 INACTIVE
The following example display the count of all IP device tracking host entries for all interfaces:
Switch# show ip device tracking all count
Total IP Device Tracking Host entries: 5
---------------------------------------------------------------------
Interface Maximum Limit Number of Entries
---------------------------------------------------------------------
Fa4/3 5
Configuring IPSG for Static Hosts on a PVLAN Host Port
You can configure IPSG for static hosts on a PVLAN host port.
To enable IPSG for static hosts with IP filters on a PVLAN host port, perform this task:
This example shows how to enable IPSG for static hosts with IP filters on a PVLAN host port:
Switch(config)# vlan 200
Switch(config-vlan)# private-vlan primary
Switch(config-vlan)# exit
Switch(config)# vlan 201
Command Purpose
Step 1
Switch(config)# vlan n1
Enters configuration VLAN mode.
Step 2
Switch(config-vlan)# private-vlan primary
Establishes a primary VLAN on a PVLAN port.
Step 3
Switch(config-vlan)# exit
Exits VLAN configuration mode.
Step 4
Switch(config)# vlan n2
Enters configuration VLAN mode.
Step 5
Switch(config-vlan)# private-vlan isolated
Establishes an isolated VLAN on a PVLAN port.
Step 6
Switch(config-vlan)# exit
Exits VLAN configuration mode.
Step 7
Switch(config)# vlan n1
Enters configuration VLAN mode.
Step 8
Switch(config-vlan)# private-vlan association 201
Associates the VLAN on an isolated PVLAN port.
Step 9
Switch(config-vlan)# exit
Exits VLAN configuration mode.
Step 10
Switch(config)# interface fastEthernet a/b
Enters interface configuration mode.
Step 11
Switch(config-if)# switchport mode private-vlan
host
(Optional) Establishes a port as a PVLAN host.
Step 12
Switch(config-if)# switchport private-vlan
host-association a b
(Optional) Associates this port with the corresponding
PVLAN.
Step 13
Switch(config-if)# ip device tracking maximum n
Establishes a maximum limit for the bindings on this
port.
Step 14
Switch(config-if)# ip verify source tracking
[port-security]
Activates IPSG for static hosts on this port.
Step 15
Switch(config-if)# end
Exits configuration interface mode.
Step 16
Switch# show ip device tracking all
Verifies the configuration.
Step 17
Switch# show ip verify source interface-name
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
