Cisco Catalyst 4500 Series Configuration Guide

14-5
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 14 Configuring the Catalyst 4500 Series Switch with Cisco Network Assistant
Configuring Your Switch for Network Assistant
Note If you have enabled clustering, disable clustering before configuring a community (see Table 14-2).
(Additional) Configuration Required to Use Community
If you plan to use community, define an IP address on each switch.
To configure a switch to use community, perform this task:
(Additional) Configuration Required to Use Clustering
If you plan to use clustering, enter the cluster run global configuration command on each device and
enter the ip address interface configuration command on the cluster commander.
To configure a switch to use clustering, perform this task:
Step 5
Switch(config)# ip http timeout-policy idle
idle_time life life_time requests requests
Configures the HTTPS port.
The idle keyword specifies the maximum amount of time a
connection can stay idle. A idle value of 180 seconds is
recommended.
The life keyword specifies the maximum amount of time a
connection can stay open since it was established. A life
value of 180 seconds is recommended.
The requests keyword specifies the maximum amount of
requests on a connection. The recommended maximum
number of requests allowed is 25.
Step 6
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 7
Switch# show running-config
Verifies the configuration.
Command Purpose
Command Purpose
Step 1
Switch# configuration terminal
Enters global configuration mode.
Step 2
Switch(config)# interface {vlan vlan_ID |
{fastethernet | gigabitethernet}
slot/interface
| Port-channel number}
Selects an interface.
Step 3
Switch(config-if)# ip address ip_address
address_mask
(Optional) Assigns an IP address to the Catalyst 4500 series.
Note This step is mandatory if the switch is part of
community or is a cluster command switch. This step
is optional if the switch is a cluster member
candidate.
Step 4
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 5
Switch# show running-config
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
