Cisco Catalyst 4500 Series Configuration Guide

39-5
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 39 Configuring VRF-lite
Configuring VRFs
Configuring VRFs
To configure one or more VRFs, perform this task:
Note For complete syntax and usage information for the following commands, see the switch command
reference for this release and see the Cisco IOS Switching Services Command Reference at:
http://www.cisco.com/en/US/docs/ios/ipswitch/command/reference/isw_book.html
Use the no ip vrf vrf-name global configuration command to delete a VRF and to remove all interfaces
from it. Use the no ip vrf forwarding interface configuration command to remove an interface from the
VRF.
Configuring VRF-Aware Services
IP services can be configured on global interfaces and within the global routing instance. IP services are
enhanced to run on multiple routing instances; they are VRF-aware. Any configured VRF in the system
can be specified for a VRF-aware service.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ip routing
Enables IP routing.
Step 3
Switch(config)# ip vrf vrf-name
Names the VRF and enters VRF configuration mode.
Step 4
Switch(config-vrf)# rd
route-distinguisher
Creates a VRF table by specifying a route distinguisher.
Enter either an AS number and an arbitrary number
(xxx:y) or an IP address and arbitrary number
(A.B.C.D:y).
Step 5
Switch(config-vrf)# route-target
{export | import | both}
route-target-ext-community
Creates a list of import, export, or import and export route
target communities for the specified VRF. Enter either an
AS system number and an arbitrary number (xxx:y) or an
IP address and an arbitrary number (A.B.C.D:y).
Note This command is effective only if BGP is running.
Step 6
Switch(config-vrf)# import map
route-map
(Optional) Associates a route map with the VRF.
Step 7
Switch(config-vrf)# interface
interface-id
Enters interface configuration mode and specify the Layer
3 interface to be associated with the VRF. The interface
can be a routed port or SVI.
Step 8
Switch(config-if)# ip vrf forwarding
vrf-name
Associates the VRF with the Layer 3 interface.
Step 9
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 10
Switch# show ip vrf [brief | detail
| interfaces] [vrf-name]
Verifies the configuration. Displays information about the
configured VRFs.
Step 11
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
