Cisco Catalyst 4500 Series Configuration Guide

12-16
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 12 Environmental Monitoring and Power Management
Power Management
Table 12-8 illustrates how the 6000 W AC power supply is evaluated in redundant mode.
In combined mode, all the inputs to the chassis must be at the same voltage.
Table 12-9 illustrates how the 6000 W AC power supply is evaluated in combined mode.
Combined Mode Power Resiliency
Note This feature only applies in combined mode when both power supply bays contain the 4200 W AC or
6000 W AC power supply.
Using the combined mode power resiliency feature, you can limit the power usage to a maximum of two
or three (configurable) inputs.
With two 4200 W AC or 6000 W AC power supplies, a maximum of four inputs are available. This
feature allows you to cap the power usage to that of two or three inputs. If one of the power supplies
fails, no loss of power occurs because you have capped its usage to a smaller number of inputs.
To configure the combined mode resiliency feature, perform this task:
220 V+220 V, other side 220 V 2200 40 4700 5500
Both sides at 220 V+220 V 2200 40 6200 7600
Table 12-7 Combined Mode Output for the 4200 W AC Power Supply
Power Supply 12 V 3.3 V -50 V Maximum
Table 12-8 Power Output in Redundant Mode for the 6000 W AC Power Supply
Power Supply 12 V 3.3 V -50 V Total
110 V 850 40 922 1050
110 V+110 V or 220V 1700 40 1850 2100
220 V+220 V 2200 40 4800 6000
Table 12-9 Combined Mode Output for the 6000 W AC Power Supply
Power Supply 12 V 3.3 V -50 V Maximum
Both sides (bays) at 110 V 1400 40 1670 1700
110 V+110 V, other side 110 V 2360 40 2560 2800
Both sides at 110 V+110 V 3090 40 3360 3700
Both sides at 220 V 4000 40 4360 5400
220 V+220 V, other side 220 V 4000 40 6600 6200
Both sides at 220 V+220 V 4000 40 8700 10900
