66-10
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 66 Configuring Cisco IOS IP SLA Operations
Configuring IP SLAs Operations
To disable the IP SLAs operation, enter the no ip sla operation-number global configuration command.
This example shows how to configure a UDP jitter IP SLAs operation:
Switch(config)# ip sla 10
Switch(config-ip-sla)# udp-jitter 172.29.139.134 5000
Switch(config-ip-sla-jitter)# frequency 30
Switch(config-ip-sla-jitter)# exit
Switch(config)# ip sla schedule 5 start-time now life forever
Switch(config)# end
Switch# show ip sla configuration 10
IP SLAs, Infrastructure Engine-II.
Entry number: 10
Owner:
Tag:
Type of operation to perform: udp-jitter
Target address/Source address: 1.1.1.1/0.0.0.0
Target port/Source port: 2/0
Request size (ARR data portion): 32
Operation timeout (milliseconds): 5000
Packet Interval (milliseconds)/Number of packets: 20/10
Step 4
frequency seconds
(Optional) Sets the rate at which a specified IP SLAs operation repeats. The
range is from 1 to 604800 seconds; the default is 60 seconds.
Step 5
exit
Exits UDP jitter configuration mode, and return to global configuration mode.
Step 6
ip sla monitor schedule
operation-number [life
{forever | seconds}]
[start-time {hh:mm [:ss]
[month day | day month] |
pending | now | after
hh:mm:ss] [ageout seconds]
[recurring]
Configures the scheduling parameters for an individual IP SLAs operation.
• operation-number—Enter the RTR entry number.
• (Optional) life—Set the operation to run indefinitely (forever) or for a
specific number of seconds. The range is from 0 to 2147483647. The
default is 3600 seconds (1 hour).
• (Optional) start-time—Enter the time for the operation to begin collecting
information:
–
To start at a specific time, enter the hour, minute, second (in 24-hour
notation), and day of the month. If no month is entered, the default is
the current month.
–
Enter pending to select no information collection until a start time is
selected.
–
Enter now to start the operation immediately.
–
Enter after hh:mm:ss to show that the operation should start after the
entered time has elapsed.
• (Optional) ageout seconds—Enter the number of seconds to keep the
operation in memory when it is not actively collecting information. The
range is 0 to 2073600 seconds, the default is 0 seconds (never ages out).
• (Optional) recurring—Set the operation to automatically run every day.
Step 7
end
Returns to privileged EXEC mode.
Step 8
show ip sla configuration
[operation-number]
(Optional) Displays configuration values, including all defaults for all IP SLAs
operations or a specified operation.
Step 9
copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
