Cisco D9824 User Manual

Setup Menu
131
Menu Item
Description
Parameters
Signal Lock Timer
Select the time, in seconds, the unit must
wait for a signal lock before declaring that
the signal is not usable and move on to the
next search location in the search path. The
default is 30 seconds.
5 to 255 seconds
Verify Timer
Select the time, in seconds, the unit must
wait for the PAT table to verify the signal
has a valid transport. The default is 60
seconds.
10 to 255 seconds
Backup Channel
Menu Item
Description
Parameters
PE #
The Program Entry (PE) number you are
configuring the backup transport channel.
PE1 to PE32
Transport
The backup transport number you are
configuring the backup channel.
1, 2, or 3
Backup Channel
The backup channel number for the
selected backup transport.
Note: We recommend that you configure a minimum of one backup transport. If no backup
transport is configured, an alarm is triggered, but the unit will not be able to switch to a
backup transport.
Backup Transport
Menu Item
Description
Parameters
Backup
The backup number
1, 2, or 3
Active
Indicates whether the selected backup is
enabled.
To activate a backup, press the ADV key
and press SELECT to insert. The Active
menu for the selected backup number
changes from No to Yes. Press APPLY to
save the changes.
To disable a backup, press the ADV key
and press the RIGHT arrow once and
press SELECT to select Delete. Press the
RIGHT arrow once and press SELECT to
select Continue. The Active menu for the
selected backup number changes from Yes
to No.
Yes or No
