Status Menu
47
Status Menu: General
Menu Item
Description
Parameters
Input
Indicates the currently selected input
source.
RF1 to RF4, ASI, or IP.
Status
Indicates whether the input signal is
locked.
Locked - Indicates the receiver is
locked to a carrier with no valid
content.
Lock+Sig - Indicates the receiver
is locked to a carrier with valid
content.
No Lock - Indicates the receiver
is not locked to a carrier.
Rate (Mbps)
Indicates the bit rate of the input transport
stream, in Mbps.
–
Level (dBm)
Indicates the strength of the received
signal level, in dBm.
–
PE
Select the Program Entry to view.
PE1 to PE32.
Mode
Indicates how the program is scrambled.
Unkn, DES, DVB, BISS1, BISS2,
or BISS3.
Auth
Indicates whether the receiver is
authorized to receive the program.
Yes or No.
Enc
Indicates whether the received program is
encrypted.
Yes or No.
Scr
Indicates whether the received program is
scrambled.
Yes or No.
CA System
Indicates the type of Conditional Access
(CA) system used by the program.
SA, BISS, or FTA (Free To Air).
Video
Indicates the video encoding, format, and
resolution of the received program.
MPEG1, MPEG2, or H264 format
with a resolution of:
SD480i/2997, SD480i/3000,
SD576i/2500, HD720p/5000,
HD720p/5994, HD720p/6000,
HD1080i/2500, HD1080i/2997,
or HD1080i/3000.
Unknown or Unsupported.
Rate (Mbps)
Indicates the bit rate of the received video
stream, in Mbps.
–
Alarms
Displays the number of active alarms.
–
Warnings
Indicates the number of active warnings.
–
