Transport Stream Inputs/Outputs
359
Transport Stream Inputs/Outputs
ASI Output
Item
Specification
Number of outputs
1
Type of connector
75 ohms BNC
Output impedance
75 ohms according to EN 50083-9
Data amplitude
800 mV peak-peak ± 10% according to EN 50083-
9
Return loss
>17 dB, 27 to 270 MHz
Transport stream data rate
1 to 180 Mbps descrambling
1 to 80 Mbps decoding
ASI Transmission Rate
270 MBaud ± 100 ppm
Transport stream formats
According to EN 50083-9
188 bytes structure
Burst or packet format
MPEGoIP Output
Item
Specification
Number of outputs
2
Type of connector
RJ-45, 100/1000BASE-T
Output modes
UDP or RTP
Redundancy modes
Manual, Auto, or Mirroring
IP Addressing
Multicast or Unicast
TS Streaming
1 MPTS or up to 32 SPTS
TS Bit Rate
1 to 180 Mbps descrambling
1 to 80 Mbps decoding
MPEGoIP bit rate
Up to 206 Mbps
FEC Support
Yes (according to pro-MPEG FEC COP#3 and
SMPTE-2022)
