Appendix A
Technical Specifications
362
Control, Management and Data Interfaces
Ethernet Management Interface
Item
Specification
Number of connectors
1
Type of connector
RJ-45
Ethernet type
100/1000BASE-T
Required setup
IP address, default gateway and subnet mask
Ethernet Data Interface
Item
Specification
Number of connectors
2
Type of connector
Eight-pin RJ-45
Ethernet type
100/1000BASE-T
Required setup
IP address, default gateway, and subnet mask
Alarm Interface
Item
Specification
Number of outputs
1, with one set of contacts closed and one set
open during normal operation.
Type of connector
15-pin sub-D female
Max. voltage
40 V peak
Max. current
0.5A
Contact Closure Interface
Item
Specification
Connector type
15-pin sub-D female
