Cisco D9824 User Manual

Video Inputs/Outputs and Processing
357
Linearity
5-step
3%
3%
Interchannel Delay
100% Color Bars
2 ns
2 ns
DC Offset
± 50 mV
± 50 mV
Return Loss
DC to 30 MHz, -20 dB
DC to 30 MHz, -20 dB
Aspect Ratio
Item
Specification
Aspect Ratio Conversions for Down-
Conversion
Aspect Ratio Conversions for SD Programs
4:3
16:9
4:3
16:9
16:9 Letterbox
14:9 Letterbox Center
Center Cutout
16:9 Letterbox
14:9 Letterbox Center
Cutout
Scale to 16:9
Audio Outputs
Analog Audio Outputs
Item
Specification
Number of Channels
2 stereo pairs/4 mono channels, 5.1 channel
downmix Audio decompression: MPEG or
Dolby Digital. HE-AAC single stereo pair or
Dolby Digital Plus single stereo pair available as
software download.
Frequency Response
±0.5 dB, 20 Hz to 20 kHz (ref., 100 kilohms)
Total Harmonic Distortion
< 0.3% at 1 kHz (ref. 100 kilohms)
Dynamic Range
85 dB (CCIR/Arm weighting)
Crosstalk
80 dB at 1 kHz (typical)
Conditional Access
Item
Specification
PowerVu CA
DES or DVB

Cisco D9824 Specifications
