Cisco D9824 User Manual

Chapter 4 Front Panel Operation
50
Status Menu: TS Input
Input
Menu Item
Description
Parameters
Input
Indicates the active input port receiving
the signal.
RF1, RF2, RF3, RF4, ASI, or IP
Status
Indicates the current signal lock status
for the input.
Locked - Indicates the receiver is
locked to a carrier with no valid
content.
Lock+Sig - Indicates the receiver is
locked to a carrier with valid
content.
No Lock - Indicates the receiver is
not locked to a carrier.
Rate (Mbps)
Indicates the bit rate of the received
input signal.
in Mbps
Level (dBm)
Indicates the signal level of the received
signal.
in dBm
SymRate
Indicates the Symbol Rate of the
received signal.
in Msymbols/second
FEC
Indicates the FEC (Forward Error
Correction) rate of the received signal.
N/A, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
7/8, 8/9 or 9/10
Modulation
Indicates the modulation type for the
received signal.
N/A, QPSK, 8PSK, DVB-S, DVB-
S2 or 16QAM
Pol
Indicates the signal polarization setting.
This setting is only applicable when
LNB Power is set to H-NIT or V-NIT.
The selected setting must match the
polarization of the transmitted signal.
Horiz (Horizontal), Vert (Vertical)
or Auto
IQ Tuner
Indicates the IQ (Input Signal Inversion)
for the received signal.
Inv or NonInv
IQ Status
Indicates the input signal spectrum
inversion setting (IQ), which allows the
operator to track and select inverted
and non-inverted digital signals.
Auto, Opposite, or Normal
Dnlk Freq (GHz)
Indicates the current downlink
frequency.
in GHz
L-Band
Indicates the current L-Band frequency.
in MHz
