Parameter
Description
Signal Status
Indicates whether the input signal is locked.
 Locked - Indicates the receiver is locked to a carrier
with no valid content.
 Lock+Sig - Indicates the receiver is locked to a carrier
with valid content.
 No Lock - Indicates the receiver is not locked to a
carrier.
Input Rate (Mbps)
Displays the bit rate of the input transport stream, in Mbps.
Acquisition State
Displays Full if the SI and PSI tables have all been found.
Otherwise, it will display Degraded if there are missing tables
or None if no SI or PSI tables have been found.
Link Status
Displays the link status of the active data port (Up or Down).
Port In Use
Displays the current input port in use (Data1 or Data2).
Transport Stream
The Transport ID (in the range from 1 to 65535).
Locked Data1/Data2
Source
When locked, this displays the source/host IP address of the
originator. If the signal is not locked, it will display N/A.
Switchover Reason
Displays a description of the reason for the last redundancy
switchover (AV Loss, Program Loss, PCR Loss, Link Loss, TS
Loss, or None).
Switchover Date/Time
Displays the last date and time for the last redundancy
switchover.
PCR Lock
Indicates whether the system is locked to the required PCR PID
(Yes or No).
De-jitter Latency (msec)
Displays the overall transport stream buffer latency, in
milliseconds.
FEC Bitrate (Mbps)
Displays the input stream bit rate reported by the FEC decoder.
FEC CEC
Indicates the current Corrected Error Count for the received
stream.
FEC PER
Indicates the current Packet Error Rate of the received stream.
