Chapter 5 Web GUI Setup and Monitoring
Each record customizes the PID or stream type to decrypt. The Index number is a
read only field that indicates the record number. You can maintain up to 64 records,
32 records for each CAM.
To insert a new record, click Add Row. A new row appears at the top of the table
(see below).
There are various configurations when creating a new record. The following table
summarizes the various methods:
Set Mode to PID and enter PID number.
Set Mode to Stream, select Stream Category (AUD, VID, SUBT, TTX,
or USER) and enter Stream Instance of the stream type.
There is an additional configuration if you select user as the Stream
Category (see below).
Set Mode to Stream, Stream Category to User, manually enter the
stream code in Stream Type Value, and then the Stream Instance of
the stream type.
If you know the PID number, ensure that PID is selected under Mode and enter the
appropriate PID number. Click Save.
To enter the stream type, choose Stream from the Mode drop-down list, choose the
stream type from the Stream Category (VID, AUD, SUBT, USER, or TTX) and enter
the instance of the stream type in Stream Instance field. You can enter a range from
1 to 64. Click Save.
If you do not know the stream type, you can specify a specific hex value as the
stream type. Choose Stream from the Mode drop-down list, choose User from the
Stream Category drop-down list, enter the hex value of the stream in the Stream
Type Value field and the instance of the customized stream type in Stream Instance
field. You can enter a two digit hexadecimal value for the Stream Type and a range
from 1 to 64 for the Stream Instance. Click Add.
