Page #230 background imageLoading...
Page #230 background image
Chapter 5 Web GUI Setup and Monitoring
208
Rate Control
Description
Auto
The output rate follows that set by the uplink. The output rate will
be the same as the input rate (including all null packets). This
means the output bit rate is determined automatically based on
the input source symbol rate and FEC value.
User
The output rate is specified by the User Rate field. It is determined
by the user setting regardless of the input source.
3 If the Rate Control is set to User, enter the maximum output bit rate in the User
Rate field. This setting is used when the signal source is RF or ASI and allows
you to set the output bit rate to a value expected by equipment connected to the
ASI output.
You can enter a range from 0 to 206 Mbps.
Note: Output data may be lost if this bit rate is set to a value less than the actual
signal bit rate.
4 Choose the DPM current output from the Output Mode drop-down list. With
the exception of No Output and Full DPM Control, choosing a mode will
configure the DPM settings to achieve the specified behavior. In this way, they
act as DPM presets. The Mode Status is changed from Unmodified to Edited by
User. We highly recommend that you use either one of these basic modes, or, for
advanced setup, enter the DPM mapping before setting the Output Mode. The
following table describes each mode:
Output Mode
Description
No Output
No ASI output will be generated and the ASI port will be disabled.
Passthrough
All PEs will be set to Pass and other DPM settings will also be set.
Service Channels
Only
This is similar to Passthrough, except that only channels applied
to program entries are available on the output.
MAP Passthrough
The output will be identical to the input, except that channels
assigned to PEs and PIDs will be mapped using the DPM settings.
If the input is tuned to a valid channel, the PEs are automatically
set to Map. Otherwise, the PEs are automatically set to Drop.
Note: If the PE is mapped, it uses the last saved output MAP
configuration. The output map (for example, output channel PMT)
does not change automatically if the input or channel number is
changed.
MAP Service
Channels Only
This is similar to MAP Passthrough, except that only channels
applied to program entries are available on the output. If the input
is tuned to a valid channel, the PEs are automatically set to Map.
Otherwise, the PEs are automatically set to Drop.
Note: If the PE is mapped, it uses the last valid input. The output
map (for example, output channel PMT) does not change
automatically if the input or channel number is changed.
