Cisco D9824 User Manual

Chapter 5 Web GUI Setup and Monitoring
224
 For PID conflicts, the system will only automatically change the duplicated
output PID numbers. If both PE actions are set to Map, the output PID
number of the higher PE is changed. Otherwise, the output PID number of
the mapped PE is changed. For example, if the PMT PID of PE1 matches the
ES PID of PE2, the ES PID of PE2 is changed. The new PID number selected is
the next number that does not appear in the output of any PE and it is not in
the current transport input.
Click Apply to save the resolved conflict changes
5 The Mode Status indicates the current DPM configuration change by a user after
changing the Output Mode. The following is a list of possible statuses:
Mode Status
Description
Unmodified
No changes were made after setting a new Output Mode.
Edited by User
DPM changes were.
Auto Re-Mapped
Output map changed automatically to fix the output channel or
PID conflicts at the time of setup.
Changed by Uplink
DPM output changes were initiated by an encoder.
6 From the Descrambled drop-down list, choose whether the receiver should
scramble the output even if it is authorized to receive the channel. The default is
Descrambled.
Descramble Mode
Description
Scrambled
Scrambles the output channel even if the PE is authorized and can
descramble the channel.
Descrambled
Descrambles the output channel, and passes in-the-clear channels.
7 Choose Yes to insert null packets in the output stream from the Null Packet
Insertion drop-down list. Otherwise, choose No. Null packets are always
inserted if the Rate Control is set to User and the configured output bit rate is
higher than the payload rate of the transport stream to be encapsulated.
Note: We recommend that the Null Packet Insertion is set to Yes.
8 In the SAP Multicast IP Address field, enter the Session Announcement Protocol
destination IP address. This is the IP address where the SAP announcements are
sent, if required.
Note: It is not recommended to change the default IP address (224.2.127.254).
9 In the SAP Destination UDP Port field, enter the SAP destination port number
(1 to 65534). This is the UDP port where the SAP announcements are sent, if
required.
Note: It is not recommended to change the default SAP port 9875.
10 From the FEC Scheme drop-down list, choose the FEC packet sending
arrangement (Block Aligned or Non-Block Aligned). They are defined in the pro-
MPEG FEC and SMPTE-2022 standards.
