Chapter 3 Installation
28
Connector
Normally
closed pin
Common pin
Normally open
pin
Relay Mode
11
10
15
Trigger
15
10
11
Alarm (default)
Note: A normally closed state implies the state when power is applied to the relay in
a normal operating state, without a trigger or alarm condition present.
