Chapter 4 Front Panel Operation
Indicates the Network ID of the uplink
signal the receiver is to receive when
using the selected preset. The receiver’s
Network ID must match the Network
ID associated with the transmitted
signal that identifies the NIT to be used.
Note: Each network must be assigned a
unique ID (number).
Indicates the Transport ID.
Indicates the current Low Noise Block
(LNB) connection status.
No Load, Over Loaded, Over
Temperature, Short Circuit,
Disabled, Normal or N/A
Indicates the polarity of the LNB Power
supply.
Indicates whether a 22 kHz tone is
available on input port RF1. This is
applicable for dual-band applications.
Program PIDs
Select the Program Entry to view.
Indicates the name assigned to the
Program Entry.
Up to 4 alphanumeric
characters
Indicates any detail associated with
the program PID (e.g., MPG2 PID).
MPG1 VID, MPG2 VID, 422
VID, H264 VID, HD VID, MPG4
VID, MPG AUD, MPG2 AUD,
DVB AC3, DVB DDP, AAC
AUD, HEAAC, AUD, MPG4
AUD, DBE AUD, DTS AUD,
DVB TXT, DVB VBI, DVB
SUBT, DVB ASYN, DVB SYNS,
DVB SYND, DVB MPE, DVB
DCAR, DVB OCAR, SA VBI,
ATSC AC3, ATSC DDP, SA
UTLD, SCTE DPI, SA HSD, SA
CDDL, SA WBD, SA SUBT,
ECM, EMM, PCR, or
UNKNOWN
Indicates the program PID number.
Indicates whether the PID is present
in the incoming stream.
