Cisco D9824 User Manual

Status Menu
55
Link Status
The Link Status parameters display the port information, such as the status, speed,
duplex and crossover. Port 1 is the management port, port 2 is the Data1 port, and
port 3 is the Data2 port.
Redundancy Status
Menu Item
Description
Parameters
Ports in Use
The current output port in use.
None, Data1, Data2, or
Both
Change Reasons
Description of the reason for the last redundancy
status change.
Link, Setup, or
Setup+Link
Change Date &
Time
Displays the last date and time the redundancy
status changed.
YYYY/MM/DD
HH:MM:SS
MOIP Out Global Status
Menu Item
Description
Parameters
Engine Error
Indicates a critical hardware error that may require
a unit reboot.
Yes or No
Stream Overflow
Indicates the MPEG over IP transport stream(s)
overflow status.
Yes or No
Combined User
Rate
Displays the combined output bit rate for all the
configured streams (including FEC).
–
Actual Rate Port
1/2
Displays the current output bit rates for Data1 and
Data2 ports (including FEC).
0 to 206 Mbps
MOIP Out Stream Status
Menu Item
Description
Parameters
PE ID
Displays the program entry channel.
1 to 32
Stream Port1/Port2
Indicates the stream status of the Data1 and Data2
ports.
Stopped, Suspended,
Active, or Muted
Content Overflow
Indicates if the rate of the transport stream(s) to be
encapsulated (including FEC) is higher than the
configured output bit rate.
Yes or No
