Chapter 4 Front Panel Operation
94
Menu Item
Description
Parameters
Auto Map
Aux
Select whether the DPM
sets the output actions for
all the auxiliary PEs to
Map when the Output
Mode is set to Transcode.
If the Fixed Output is set
to Yes, the output
configuration for the
auxiliary PEs is
determined by the fixed
output table options when
you resynchronize the
output channels and PIDs
to match the input
programs.
Note: The DPM resolves
any output conflicts
automatically, even if the
Auto Map is set to No.
Yes or No
MOIP
Menu Item
Description
Parameters
Name
This is the name assigned to the
transport output for ease of
reference.
20-character string
Rate Control
This is the DPM output rate
control.
Auto - The output rate follows that set by the
uplink. This setting can be used if the signal
source is ASI. If Insert Null Packet is set to
Yes, the output bit rate is the same as the
input rate (including all the null packets). If
Insert Null Packet is set to No, the output rate
is equal to the payload rate of the transport
stream to be encapsulated, and in most cases,
it will be lower than the overall input rate.
User - The output rate is specified by the User
Rate parameter. It is determined by the user
setting regardless of the input source. Null
packets are always inserted when the
configured output bit rate is higher than the
payload rate of the transport stream to be
encapsulated.
