Startup Screen
41
LCD Symbol
Description
The Left/Right symbol indicates that the
RIGHT/LEFT arrow key is active; for example,
pressing the RIGHT/LEFT arrow key will have an
affect, such as moving the cursor to the right/left.
The up/down symbol indicates that the UP/DOWN
arrow key is active.
The Download In Progress (DL) symbol indicates that
the transcoder is currently downloading a software
update and storing it into memory in the background.
Note: Service interruption occurs during a reboot,
which is always required when the software is
updated.
The Download Trigger (DT) symbol indicates new
software is ready for download, but a download
trigger by the transcoder is required before it will be
downloaded.
Note: Service interruption occurs during a reboot,
which is always required when the software is
updated.
The Download symbol indicates that a software
download for a version of software already in memory
has been detected.
The Disaster Recovery (DR) symbol indicates that a
disaster is declared on the current transcoder.
The NIT Retune (NR) symbol indicates that a NIT
retune recovery is in progress on the current
transcoder.
o
The Session Open symbol indicates that you are
changing a group of related items.
Assigning Program to the Program Entry
To assign a program to the PE:
1 Press MENU until you display the startup screen.
s
PE1 706 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #PE #
