Video Inputs/Outputs and Processing
339
Item
Test Signal
Specification CVBS1
Specification CVBS2
Luminance
Non-linearity
VITS17
< 5%
< 5%
Weighted Signal
Video-to-Noise
50% Grey Field
≤ -70 dB rms
≤ -70 dB rms
Weighted Signal
Video-to-Noise
Luminanace
Ramp
≤ -55 dB rms
≤ -55 dB rms
Return Loss
DC to 10 MHz, > 30 dB
DC to 10 MHz, > 30 dB
Audio Inputs/Outputs
Analog SD Video Output, CVBS1 and CVBS2 for m onitoring
Item
Specification
Number of Channels
One down-converted source HD program
Video Decompression Type
MPEG-2 4:2:0
Output Level
1.0 Vpp ± 5%
Output Impedance
75 ohms
Analog Audio Inputs
Item
Specification
Number of Channels
2
Audio Decompression
MPEG or Dolby Digital (AC-3)
Analog Audio Outputs
Item
Specification
Number of Channels
2 stereo pairs or 4 mono channels
Audio Decompression
MPEG or Dolby Digital (AC-3), SMPTE 276M
